Display
LCD, TFT, Touch
Wall device
Finery, Floating
Self calibration
The microprocessor-controlled CO2 measuring device is used to record the CO2 content, temperature and air humidity. The display shows the measuring signals numerically or alternatively as traffic light or graphically.
The CO2 content is determined by means of an optical sensor, non dispersive infrared technology. By using the sensor according to the dual principle, interferences of the measurement by pollution and aging can be excluded as far as possible, so that a long function time of the device is ensured. No calibration is needed under normal conditions. Temperature and humidity serve as additional displays of information. The application area of the CO2-meter homeDesigm is primarily recommended in private rooms, offices, classrooms or meeting rooms. A controlled airflow controls the maximum CO2 concentration in the room and keeps it within limits, wich increases the ability to concentrate. This CO2 measuring device is intended as a wall device for mounting on a flush-mounted box.
- The CO2 sensor uses an infrared technique to measure the content of CO2 in air.
- 6 colour LEDs permit a visualization of CO2 content (in stages from 0 ppm – 2000 ppm).
- Ideal for use as a desktop device in classrooms and offices.
